SmartPak® Plus Residential Alternator


SmartPak® Plus Residential Alternator

Accessories

Allows you to install two automatic pumps up to 1/2 HP and alternate their use by connecting the built-in auxiliary contacts to a Z Control Gateway or APak, users can receive alerts via email, text, and push notifications.

  • Features & Benefits

    Features

    • Alternates two automatic pumps up to 1/2 HP, 12 Amps each, 115 V single phase (not to be used with Model 63 or Model 95 pumps or with any model grinder pumps)
    • Extends pump life
    • Compact design easily mounts in confined spaces and is equipped with cutting-edge electronics
    • Circuit fault protection
    • Specially designed for humid areas like basements
    • Universal connection for alarm switch replacement
    • Auxiliary output contacts (normally open) for remote alarm connection
    • Connect to input terminals on either the Z Control® APak® or Gateway and receive alarm notifications via email, text, and app push through the Z Control® Cloud.
    • Built-in, rechargeable battery
    • 9′ power cord
    • 2 year limited warranty

    Alarms

    • Multiple alarm modes will alert user to potential problems and protect property by switching to the other pump when necessary.
      • High water alarm operation
      • Loss of power alarm operation
      • Continuous pump run alarm operation
      • Breaker tripped alarm operation
      • Pump failure alarm operation
    • Built-in rechargeable battery will operate the alarm and LED lights for a limited time during power outage.
    • Button for Silence and Reset
    • Receive alarms through Z Control® Cloud! See FM3010.

    Indicator Lights

    • Solid green LED lights for Pump 1 and Pump 2 and Power
    • Flashing red LED lights for alarm conditions
